Desktop Mechanical Heated Ultrasonic Cleaner YR05234 // YR05243

Manufacturer: Kalstein

Description

The YR05234-YR05243 Heated Ultrasonic Cleaner Series is an advanced solution designed for high-precision cleaning, capable of removing even the smallest dirt particles from hard-to-reach areas like deep holes, fine crevices, and hidden spots. Thanks to its MCU-swept ultrasonic driver circuit, it ensures optimal cleaning performance while keeping noise levels to a minimum. Each model in the series is equipped with a high-performance industrial ultrasonic transducer, which maximizes energy conversion efficiency and ensures a long service life.

The YR05234 to YR05243 models range in size and capacity, with volumes from 3.2 liters to 30 liters, making them suitable for various industrial and laboratory needs. The 1.0 mm thick SUS304 stainless steel tanks are highly durable and deliver excellent performance. Additionally, the machine features a digital heating control and mechanical timer, allowing cleaning times between 1 and 60 minutes, with adjustable temperatures of up to 80°C, ensuring deep and efficient cleaning. For instance, the YR05243 model comes equipped with a drain valve and 600W ultrasonic power, making it ideal for demanding applications.

Market Price

This type of heated ultrasonic cleaning equipment ranges from $240 to $1050 USD, depending on the capacity and technical specifications.

Frequently Asked Questions

  • What kind of parts can I clean with this equipment?
    It can be used to clean metal, electronic, and glass parts, making it ideal for sectors such as healthcare, manufacturing, and laboratories.
  • Is the tank corrosion-resistant?
    Yes, it is made of SUS304 stainless steel, known for its corrosion resistance.
  • Can I control the temperature?
    Yes, the equipment includes a digital temperature control that allows adjustments between 30°C and 80°C.

Pros and Cons

The YR05234-YR05243 heated ultrasonic cleaner series offers several key advantages, including the ability to thoroughly clean hard-to-reach areas, energy efficiency thanks to its industrial ultrasonic transducer, and the durability of its stainless steel tank. Its user-friendly operation with a timer and temperature control makes it versatile for various applications. One potential downside is that models with larger capacities, such as the YR05243, may be less portable due to their size and weight.

Field Use

This type of ultrasonic cleaner is ideal for use in laboratories, clinics, and industrial sectors where high-precision cleaning is required. In the medical field, for example, it can be used to clean surgical and dental instruments. In the industrial sector, it is useful for cleaning mechanical parts or electronic components that require a level of cleanliness that traditional methods cannot achieve.

Recommendations

To maximize the equipment’s lifespan, it is recommended to perform regular maintenance, especially on the tanks, ensuring they are dry and clean after each use. Avoid overloading the tank with excessively large or numerous parts to ensure uniform cleaning. Additionally, using specialized cleaning solutions can enhance the results.

If you are looking for a reliable and high-performance cleaning solution, we invite you to request a quote or generate an automatic quote through the Kalstein Plus platform. Make sure to choose the model that best suits your needs, whether you prefer a compact option like the YR05234 or a larger capacity model like the YR05243.

Technical Specifications

Model YR05234 YR05235 YR05236 YR05237 YR05238
Internal dimensions 240*135*100 240*135*150 300*150*100 302*150*150 300*240*150
External dimensions 268*170*243 268*170*290 325*178*243 325*178*290 368*270*290
Volume
(L)
3.2 5 4.8 6.8 11
Gross weight
(KG)
4.77 5.4 5.65 6.2 8.5
Ultrasonic
Power (W)
120 120 180 180 240
Power of
heating (W)
100 200 200 200 300
Drain valve no no no yes
Frequency
(kHz)
40
Hour
(Min.)
1-60
Heating
Temperature (℃)
30~80



Model YR05239 YR05240 YR05241 YR05242 YR05243
Inner dimensions 330*300*150 330*300*200 500*300*150 500*300*200
External dimensions 397*320*317 397*320*368 560*320*317 560*320*385
Volume
(L)
15 20 22 30
Gross weight
(KG)
11.5 12.5 14.5 16
Ultrasonic
Power (W)
360 360 480 600
Power of
heating (W)
400 400 500 500
Drain valve yes yes yes
Frequency
(kHz)
40 28
Time
(Min.)
1-60
Heating
Temperature (℃)
30~80

Additional information

Weight N/A
Dimensions N/A
Model

YR05234, YR05235, YR05236, YR05237, YR05238, YR05239, YR05240, YR05241, YR05242, YR05243
