Description
- Special Designed Sample Digestion Vessel The automatic vent and self-resealing structure which won national patent ensures the digestion vessels can automatically release pressure and instantly reseal when a sudden over-pressure situation occurs. It prevents waste of batch samples and solutions and also avoids vessel damage.
- Contact-less Temperature and Pressure Monitoring System. The advanced contact-less IR sensor could measure the real-time temperature of sample solutions in each digestion vessel. Meanwhile, the contact-less pressure sensor could monitor the real-time pressure of each vessel. This realizes isolation between temperature and pressure controlling system, also avoids sample cross-contamination. Each real-time temperature and pressure value is displayed during the whole digestion process, allowing a clear check of digestion conditions.
- Large Storage Capacity. It can edit and store 255 types of programs according to user’s requirements and each method program can set parameters (temperature, pressure, time, microwave power) according to their own requirements which provides convenient operation for users.
- Safety Protection System. With high-strength double locked security door, the real-time temperature and pressure monitoring, automatic adjustment of over-pressure and over-temperature and abnormal sound monitoring, the device can run in a highly safe environment.
- Power Adjustment. The variable frequency resonance or non-pulse(optional) continues rotating mode ensures high efficient and even microwave throughput. It can be set between 0~3000W according to user’s requirements.
Quality components
- 360º continuous rotor makes the rotation in a same direction. It ensures even andcomplete digestion, also reduces the wear and tear of motor, which greatly extend its service life.
- Color 7 inches LCD touch-screen displays the real-time temperature and pressure, alsothe working time and tendency curves.
- The material of sample digestion vessel is imported TFM. For outer protection vessel, it is imported PEEK and glass fiber which could prevent high temperature, high pressure and acid corrosion.
Technical Specifications
Model | YR04959 | YR04960 |
Vessel Quantity | 40 | 50 |
Temperature Monitoring System | Contactless IR Sensor Temperature Monitoring | |
Each Vessel Temperature Controlled | ||
Temperature Controlling Range: 50~400℃ | ||
Temperature Accuracy: ±0.3℃ | ||
Display Accuracy: ±0.1℃ | ||
Pressure Monitoring System | Contactless Sensor Pressure monitoring | |
Each Vessels Pressure Controlled | ||
Pressure Controlling Range: 0~10MPa | ||
Pressure Accuracy: ±0.01MPa | ||
Display Accuracy: ±0.01Mpa | ||
Vessel Volume | 50mL | |
Sample Vessel Material | Imported TFM | |
Protection Vessel Material | Peek+Glass Fiber | |
Display | 7 inch Color Touch Screen | |
Rotation | One Direction 360° continuous rotating | |
Microwave Tank | 316L stainless steel tank with corrosion-proof coating | |
Microwave Power | 0-3000W (Adjustable) | |
Microwave Leakage | <5mw/cm2 | |
Air Exhaust | High power corrosion-proof air blower | |
Power | AC 220V±10%, 10A, 50/60Hz | |
Dimension | 640×630×590mm(L×W×H) | |
Weight | 78KG |
