Ion meter
An Ion is an atom or a group of atoms with an electric charge. This charged particle can be positive or negative. A cation is a positively charged ion, and an anion is a negatively charged ion (atom or molecule). Ions are formed when a neutral (electrically neutral) atom loses or gains electrons. Anions have more electrons than protons, and cations have higher proton numbers.
Measurement of ion concentration or specific ion measurements through an ion meter it can be performed on a wide variety of samples such as water, food, beverages, pharmaceuticals and samples of biological origin.
Type Ion Meter a Laboratory May Need
Portable
Ion Mode
• The portable multi-parameter ion meter is equipped with a backlit LCD screen.
• Calibration from 2 to 5 points, including 8 concentration points, can be selected.
• Direct ion concentration reading simplifies the measurement process.
• The automatic diagnosis of the electrode shows the calibration points and slopes.
• Selectable concentration units (PPM, MG/L, MOL/L) and ionic valence.
pH mode
• Auto-recognition 1-5 point calibration for U.S., NIST, and DIN shock absorbers.
• The automatic diagnosis of the electrode shows the pH slope and displacement.
ORP mode
• The 1-point offset calibration allows the displayed value to be adjusted to a known standard.
• Relative and absolute millivolt modes ensure reliable Orp measurements.
In Kalstein you can find the Ideal Ion Meters for your Laboratory
Portable Ion Meter YR01817 // YR01817-15
Professional portable ammonium ion meter, suitable for outdoor applications, accuracy: 0.5% F.S...
Portable pH / Ion Meter YR01816
Multiparameter portable ion meter, 2 to 5 points calibration, selectable ion concentration units...
Our Best Selling Ion Meter
Features
- The professional portable ammonium ion meter is equipped with a backlit LCD display.
- Calibration from 2 to 5 points from low to high concentrations.
- Selectable concentration calibration points from 8, including 0.001 to 10000.
- Selectable concentration units – PPM, MG/L and MOL/L.
- Automatic electrode diagnostics displays calibration points and slopes.
- Automatic temperature compensation ensures accurate readings over the entire range.
- Direct ion concentration readout simplifies the measurement process.
- Automatic readout function The end point of the measurement is detected and locked.
- Calibration Due Alarm prompts the user to regularly calibrate the meter.
- Setup menu allows you to configure the number of calibration points, stability criteria, temperature
- Unit, date and time, etc.
- Reset function automatically resets all settings to factory defaults.
- Expanded memory stores or recalls up to 500 data sets.
- USB communication interface for data transfer or by connecting a power adapter to the meter.
| Model | YR01817 | YR01817-1 | YR01817-2 | YR01817-3 | YR01817-4 | YR01817-5 | YR01817-6 | YR01817-7 |
| Ion concentration | ||||||||
| Range | 5 × 10-6 to 1 M, 0,1 to
18000 ppm |
5 × 10-6 to 1 M, 0,4 to
79900 ppm |
5 × 10-7 to 1 M, 0,02 to
4000 ppm |
5 × 10-6 to 1 M, 1,8 to
35500 ppm |
5 × 10-6 to 0,01 M, 0,2 to
260 ppm |
1 × 10-6M to saturation,
0.02ppm to saturation |
7 × 10-6 to 1 M, 0,4 to
62000 ppm |
1 × 10-7 to 1 M, 0,01 to
107900ppm |
| Resolution | 0,001, 0,01, 0,1, 1 | |||||||
| Accuracy | ± 0.5% FS | ± 0.5% FS | ± 1% FS | ± 0.5% FS | ± 1% FS | ± 0.5% FS | ± 0.5% FS | ± 1% FS |
| Calibration points | 2 to 5 points | |||||||
| Calibration solutions | 0,001, 0,01, 0,1, 1, 10, 100, 1000, 10000 | |||||||
| Units of measure | ppm, mg / L, mol / L, mmol / L | |||||||
| mV | ||||||||
| Range | ± 1999,9mV | |||||||
| Resolution | 0,1 mV | |||||||
| Accuracy | ± 0,2 mV | |||||||
| Temperature | ||||||||
| Range | 0 a 105 ° C / 32 a 221 ° F | |||||||
| Resolution | 0,1 ° C / 0,1 ° F | |||||||
| Accuracy | ± 0,5 ° C / ± 0,9 ° F | |||||||
| Compensation calibration | 1 point | |||||||
| Calibration range | Reading ± 10 ° C | |||||||
| General specifications | ||||||||
| Temperature compensation | 0 to 100 ° C / 32 to 212 ° F, manual or automatic | |||||||
| Stability criteria | Low or high | |||||||
| Calibration alarm expired | 1 to 31 days or rest | |||||||
| Automatic shutdown | 10, 20 or 30 minutes after the last key is pressed | |||||||
| Memory | Stores up to 500 data sets | |||||||
| Production | USB communication interface | |||||||
| Connector | BNC, 3.5 mm jack connector | |||||||
| Monitor | Customized LCD (80 × 60 mm) | |||||||
| Energy | 3 x 1.5V AA batteries or DC5V power adapter | |||||||
| Battery life | Approximately 150 hours (turn off backlight) | |||||||
| Dimensions | 170 × 85 × 30 mm | |||||||
| Weight | 300g | |||||||
| Model | YR01817-8 | YR01817-9 | YR01817-10 | YR01817-11 | YR01817-12 | YR01817-13 | YR01817-14 | YR01817-15 |
| Ion concentration | ||||||||
| Range | 1 × 10-5 to 1 M, 0,1 to 23000 ppm | 1 × 10-6 to 0,1 M,
0,01 to 11200ppm |
1 × 10-8 to 0,1 M,
0,006 to 6400 ppm |
5 × 10-8 to 1 M,
0,06 to 127000ppm |
1 × 10-8 to 0,1 M, 0,2 to 20700 ppm | 1 × 10-6 to 1 M, 0,04 to 39000 ppm | 1 × 10-7 to 1 M, 0,003 to 32100 ppm | 1 × 10-6 a 1 M, 0,02 a
17000 ppm |
| Resolution | 0,001, 0,01, 0,1, 1 | |||||||
| Accuracy | ± 0.5% FS | ± 1% FS | ||||||
| Calibration points | 2 to 5 points | |||||||
| Calibration solutions | 0,001, 0,01, 0,1, 1, 10, 100, 1000, 10000 | |||||||
| Units of measure | ppm, mg / L, mol / L, mmol / L | |||||||
| mV | ||||||||
| Range | ± 1999,9mV | |||||||
| Resolution | 0,1 mV | |||||||
| Accuracy | ± 0,2 mV | |||||||
| Temperature | ||||||||
| Range | 0 a 105 ° C / 32 a 221 ° F | |||||||
| Resolution | 0,1 ° C / 0,1 ° F | |||||||
| Accuracy | ± 0,5 ° C / ± 0,9 ° F | |||||||
| Compensation calibration | 1 point | |||||||
| Calibration range | Reading ± 10 ° C | |||||||
| General specifications | ||||||||
| Temperature compensation | 0 to 100 ° C / 32 to 212 ° F, manual or automatic | |||||||
| Stability criteria | Low or high | |||||||
| Calibration alarm expired | 1 to 31 days or rest | |||||||
| Automatic shutdown | 10, 20 or 30 minutes after the last key is pressed | |||||||
| Memory | Stores up to 500 data sets | |||||||
| Production | USB communication interface | |||||||
| Connector | BNC, 3.5 mm jack connector | |||||||
| Monitor | Customized LCD (80 × 60 mm) | |||||||
| Energy | 3 x 1.5V AA batteries or DC5V power adapter | |||||||
| Battery life | Approximately 150 hours (turn off backlight) | |||||||
| Dimensions | 170 x 85 × 30mm | |||||||
| Weight | 300g | |||||||
Analysis of the best Ion MeterS for your laboratory
Food Analysis Using the Potassium Ion Meter
The potassium meter is a portable, safe and simple to operate. This device is essential for the...
How is Hydrogen Sulfide Detected with the Ion Meter?
Ion Meters are equipment designed to measure and control the purity of the water, they are also used...
Ion and Conductivity Meters: Differences
The methodology used by ion meters with selective Ion electrodes is ion exchange, which measures the electrodes of the ion...
How are Ions
measured?
Ions are atoms or groups of atoms that have charge, they differ according to the charge they present...
Ion Meter Models Catalog on Sale
Guides to Becoming an Expert in Ion Meter
What is the Ion Meter used for?
- Kalstein
The Ion Meter is a piece of equipment used to detect the concentration or activity of ions in a solution. There are different types of ion...
What are the characteristics of an Ion Meter?
An Ion Meter is an electrochemical analytical device that is used to measure ion concentration in a solution. It is used with several ion...
How does a laboratory Ion Meter work?
- Kalstein
A selective ion electrode is a kind of sensor that allows to test Ions in various types of samples, whether environmental, pharmaceutical...
Use of Ion Meters for Lead Determination of Samples in the Laboratory
The lead Ion Meters, is a complete analytical device with silver / silver chloride (Ag / AgCl) reference placed inside a plastic cover with a potassium nitrate electrolyte...
Video of our Ion Meter in operation
In this section you can find, our Ion Meter in operation, packaged, receiving service, etc...
Ion Meter operating
Features
• The professional portable copper ion meter is equipped with a backlit LCD screen.
• Calibration of 2 to 5 points from low to high concentrations.
• Selectable concentration calibration points of 8, including 0.001 to 10000.
• Selectable concentration units - PPM, MG / L and MOL / L.
• The automatic electrode diagnosis shows calibration points and slopes.
• Automatic temperature compensation ensures accurate readings over the entire range.
• The direct ion concentration reading simplifies the measurement process.
• Auto Read Function The end point of the measurement is detected and locked.
• Calibration Due Alarm Requestors the user to calibrate the meter regularly.
• Set-up menu allows you to set the number of calibration points, stability criteria, temperature Unit, date and time, etc.
