Description
- UV wavelength available, including 340nm.
- 3 test methods: End Point, Fixed time and Kinetic.
- Temperature control, incubation time and temperature adjustable.
- Compact design, PC controlled system, Windows XP.
- User-friendly software offers simple operation.
Technical Specifications
| Model | YR05127 |
| Readout range | 0.000~4.000Abs |
| Plate type | 96-well plate |
| Measure system | 8-channel optical system |
| Wavelength | 405, 450, 492, 630 nm, two more optional filters |
| Bandwidth and accuracy | 8 nm ± 2 nm |
| Light source | Monochromatic LED |
| Reading speed | 5s with single wavelength for whole plate |
| Repeatability | ＜1% |
| Weight | 6 kg |
| Stability | ＜0.005Abs/10 min |
| Shaking | 3 shaking modes with variable time |
| Input | Mouse, Membrane keyboard, Touch screen |
| Display | 7″ TFT LCD, 800×480 pixels |
| Printer | Built-in printer, external printer |
|
Working conditions
|
Power supply AC 100~240V, 50/60Hz |
| Temperature 10 °C~35 °C | |
| Humidity 15%~85% | |
| Dimension (mm) | 400(L) x 310(W) x 169(H) |
