Description
The Portable Conductivity/DO Meter YR06382 is an indispensable tool for field and laboratory professionals looking to measure conductivity and dissolved oxygen with accuracy and ease. Featuring a large, easy-to-read LCD screen with controllable backlight, this portable meter is equipped with a microprocessor for automatic calibration, data storage, and auto power-off to save battery life. With the ability to measure conductivity across multiple ranges and provide high precision TDS and salinity conversion, this device is versatile and highly reliable for scientific applications.
Market Price
For those considering the purchase of a Portable Conductivity/DO Meter, the price range can vary significantly depending on the features and brand. Generally, high-quality meters like the YR06382 are available between $700 and $800 on the market. It’s a valuable investment for those seeking precision and reliability in their measurements.
Frequently Asked Questions
Q: How long does the battery last?
A: The meter operates on two AA batteries which offer prolonged usage with efficient power-saving functions.
Q: Is the meter waterproof?
A: Yes, the YR06382 has an IP57 rating, ensuring it is both dustproof and waterproof.
Advantages and Disadvantages
Advantages: The meter provides fast response times, precise measurements, and multi-range conductivity capabilities. It’s highly portable and user-friendly.
Disadvantages: While the device offers outstanding features, users may need to manually perform pressure compensation in certain scenarios, which can be less convenient for new users.
Field Usage
The YR06382 meter is ideal for on-site measurements in environmental studies and agricultural applications. Its multi-range capabilities allow users to switch between conductivity, TDS, salinity, and resistivity measurements with ease. This versatility makes it an excellent choice for professionals requiring reliable and accurate field data.
Recommendations
To ensure the best performance from your Portable Conductivity/DO Meter YR06382, regular calibration and proper maintenance are essential. Store the device in a dry place, replace batteries as needed, and clean the electrodes after each use to maintain accuracy.
Features
- Large LCD with backlight
- Automatic calibration and data storage
- Multi-range conductivity functionality
- IP57 dustproof and waterproof rating
- Polarographic DO electrode with short polarization time
Technical Specifications
| Model | YR06382 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~19.99)μS/cm | ||
| (20.0~199.9)μS/cm | ||
| (200~1999)S/cm | ||
| (2.00~19.99)mS/cm | ||
| (20.0~199.9)mS/cm | ||
| TDS:(0~100)g/L | ||
| Salinity:(0~100)ppt | ||
| Resistivity:(0~100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1 mS/cm | |
| Accuracy | ±1.0% FS, Overall:±1.5% FS | |
| Temp. compensation | (0~100)ºC(Auto/manual) | |
| Electrode constant | 0.1 / 1 / 10 cm-1 | |
|
DO
|
Measuring range | (0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Instrument: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp. compensation | (0 ~ 45)ºC (auto) | |
| Salinity compensation | (0 ~ 45) ppt (auto) | |
| Pressure compensation | (66 ~ 200) kPa (manual) | |
| Auto calibration | Air saturated by water, water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Measuring range | (0 ~ 100)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Data storage | 200 sets |
| Power | Two AA batteries (1.5V x2) | |
| Ambient Temp. | 5 ~ 35 ºC | |
| Ambient humidity | ≤85% | |
| IP grade | IP57 Dustproof and waterproof | |
| Dimensions/N.W. | (65×120×31)mm/180g | |
| Shipping size/G.W. | (460×300×55)mm/1Kg | |
