Description
Fully automatic silent design
Free choice of three flow rates: 4L/6L/10L
Special insufflator for animals, especially for small animals like dogs, cats, etc.
Automatic alarm function and safe procedure monitoring
To provide wide view and surgical space for animal laparoscopic surgery to connect with CO2 cylinders
Technical Specifications
| Model | YR06157 |
| Flow rate | 4L/min, 6L/min, 10L/min |
| Maximum flow rate | 10L/min, adjustable |
| Preset pressure | 0.67kPa~3.30kPa (5mmHg~25mmHg) |
| Control accuracy | ±0.13kPa (1mmHg) |
| Power | 40w |
| Gas source | medical CO2 |
| Working pressure alarm | When it exceeds 4.40kPa±5% (i.e. 33mmHg±5%) for more than 3 seconds, it will alarm and relieve the pressure to the set pressure. |
| Cylinder pressure alarm | When the cylinder gas output pressure is ≤0.29MPa (3kgf/cm2), the insufficiency machine will alarm to remind ventilation. |
| Ambient temperature | 5℃~40℃ |
| Relative humidity | 30~75% |
| Atmospheric pressure | 70kPa~106kPa |
| Power supply | AC 220V, 50Hz |
