YR01829 Benchtop Conductivity Meter

Manufacturer: Kalstein

Description

  • 7-inch colored capacitive touch screen with high resolution (1024*600) and sensitivity.
  • Built-in microprocessor chip has Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, wireless printing, and self-diagnosis information, etc.
  • It supports wireless bluetooth printing. Real-time data transfer to mobile phone via bluetooth is optional.
  • Smart electrode status display to ensure accurate use.
  • Adopt advanced conductivity measurement technology, with conductivity electrode (K=1), it can meet measuring accuracy requirement for range of 0.5uS/cm ~ 200mS/cm.
  • Ability to switch among conductivity, TDS, salinity and resistivity. Multinomial calculation for TDS and salinity to ensure the conversion precision of the full range.
  • With ATC conductivity electrode, its measurement result is fast and precise.
  • Auto recognition of 8 conductivity standard solution with 2 kinds of options: Europe & USA, and China.
  • Can store 2000 sets of test data, which can be saved and transferred to USB memory stick and opened with Excel.
Technical Specifications
Model YR01829
pH
Measuring range (-1.999 ~ 19.999)pH
Resolution 0.1/0.01/0.001 pH
Accuracy Electrode: ±0.002 pH, Meter: ±0.01 pH
Auto calibration 1, 2, 3 point
Buffer Europe & USA, NIST, China standards
Input current ≤1×10 -12 A
Input impedance ≥3×10 12Ω
Stability ±0.002 pH/3h
Temp. compensation (0 ~ 100)°C, auto or manual
mV
Measuring range -1999.9mV ~ 0 ~ 1999.9mV
Resolution 0.1 mV
Accuracy ±0.03% FS
Cond.
Measuring range
Conductivity
(0.00~20.00)μS/cm, (20.0~200.0)μS/cm
(200~2000)μS/cm, (2.00~20.00)mS/cm
(20.0~200.0)mS/cm
(200~2000)mS/cm (K=10)
TDS: (0 ~ 100)g/L
Salinity: (0 ~ 100)ppt
Resistivity: (0 ~ 100)MΩ·cm
Resolution 0.01/0.1/1μS/cm; 0.01/0.1/1mS/cm
Accuracy Electrode: ±0.5% FS, Meter: ±0.8% FS
Temp. compensation range (0 ~ 100)°C, auto Electrode constant 0.1/0.5/1/5/10/50/100 cm -1
Reference Temp. 25°C, 20°C, 18°C
Temp.
Range (-10 ~ 110)°C
Resolution 0.1°C
Accuracy 5 ~ 60°C:±0.4°C Others: ±0.8°C
Other
Display 7-inch colored capacitive touch screen
Data storage 1000 sets
Power 12V/1A
Output USB
Ambient Temp. 15 ~ 30 °C
Ambient Humidity ≤85%
IP grade IP54
Dimensions/N.W. 215×170×37mm/600g
Shipping Size/G.W. 470x430x72mm/3kg

Additional information

Weight 3 kg
Dimensions 47 × 43 × 8 cm
