Description
The Heating Mantle YR05039 // YR05048 is an essential tool for laboratories looking for reliable and precise heating solutions. Crafted from high-quality cold rolled steel with a protective surface spray, this heating mantle promises durability and minimal heat-up time. Equipped with advanced precise PID temperature control, it ensures accuracy for high-experiment demands. The YR05039 model is ideal for single-position applications with an outer sensor, while the multi-position models like the YR05048 are designed with inner sensors, all capable of utilizing an optional outer sensor for enhanced control.
Market Price Overview
The Heating Mantle YR05039 // YR05048 offers exemplary performance with a price range typically seen between $110 and $330 in the laboratory equipment market. This pricing reflects its high-quality build and technological features, positioning it as an affordable yet sophisticated option for laboratory professionals. For the most competitive pricing, consider requesting a quote or generating one automatically through our platform, Kalstein Plus.
Frequently Asked Questions
- What is the maximum temperature this heating mantle can reach? This model can achieve a maximum temperature of 380°C, making it suitable for various laboratory applications.
- Is the heating mantle easy to operate? Yes, the device is designed with user-friendly controls and interfaces, ensuring simple and effective use.
Advantages and Disadvantages
Advantages: Efficient heating with nichrome wire, long service life, precise temperature control, and easy handling are notable benefits. Additionally, the inclusion of sensors enhances its versatility and accuracy.
Disadvantages: High operating temperatures may require careful handling to maintain safety. Some users may need additional training to fully utilize all advanced features.
Product Use in the Field
The Heating Mantle YR05039 // YR05048 is perfect for laboratories engaged in chemical, pharmaceutical, or biological research that requires controlled heating processes. Its versatile capacity options make it suitable for diverse experimental setups, from small-scale reactions to larger experiments requiring high precision and reliability.
Recommendations
To maximize the efficiency and life span of your heating mantle, ensure regular maintenance, including cleaning and checking sensor calibrations. Operate the mantle within the recommended voltage and temperature ranges to prevent damage. For optimal performance, consider training sessions for users unfamiliar with digital or analog heating technologies.
Features
- Constructed with a robust cold rolled steel shell and spraying treatment for enhanced durability.
- Features nichrome heating wire for quick heat-up and a long lifespan.
- Equipped with precise PID temperature control for high accuracy.
- Available in both analog and digital models with optional outer sensor configurations.
- Compatible with 200 – 240V / 50 – 60Hz or 100 – 120V / 50 – 60Hz power settings.
Technical Specifications
| Type | Analog | ||||
| Model | YR05039 | YR05040 | YR05041 | YR05042 | YR05043 |
| Capacity (ml) | 100 | 250 | 500 | 1 000 | 2 000 |
| Voltage (V) | 200 – 240V / 50 – 60Hz or 100 – 120V / 50 – 60Hz | ||||
| Max Use Temperature(°C) | 380 | ||||
| Speed (W) | 100 | 150 | 250 | 350 | 450 |
| Speed (r.p.m) | 0 – 1 600rpm | ||||
| Working Time | Continu | ||||
| Exterior Size(mm) | Ø200×165 | Ø260×200 | Ø300×230 | ||
| Packing Size(mm) | 230 x 210 x 195 | 290x290x220 | 330x330x250 | ||
| Net Weight (kg) | 2.5 | 4.5 | 6.5 | ||
| Gross Weight(kg) | 3.5 | 5.5 | 7 | ||
| Type | Digital | ||||
| Model | YR05044 | YR05045 | YR05046 | YR05047 | YR05048 |
| Capacity (ml) | 100 | 250 | 500 | 1 000 | 2 000 |
| Voltage (V) | 200 – 240V / 50 – 60Hz or 100 _ 120V / 50 – 60 Hz | ||||
| Max Use Temperature(°C) | 380 | ||||
| Speed (W) | 100 | 150 | 250 | 350 | 450 |
| Speed (r.p.m) | 0 – 1 600rpm | ||||
| Working Time | Continu | ||||
| Exterior Size(mm) | Ø220 x 165 | Ø260 x 200 | Ø330 x 230 | ||
| Packing Size(mm) | 230x210x195 | 290x290x220 | 345x290x350 | ||
| Net Weight (kg) | 2.5 | 4.5 | 6.5 | ||
| Gross Weight(kg) | 3.5 | 5.5 | 7 | ||
