Product Description
Light sources with four colors( Green, Amber, Red and Warm/Cold White) are mixed excatly where it is created (in the unique light beam condensor)- but not in the surgical field, which brings super high CRI (Ra>=95).Meanwhile, the New Light Source requires less LEDs to reach a ideal illuminance with lower irradiated heat.
| Model | YR02106 | YR02108 | YR02110 | YR02112 |
| Central illuminance (KLux) | 120-140 | |||
| Color temperature (K) | 3650-5000 10 level adjustment | |||
| Point field (d10) (mm) | 160-320 | |||
| d10 / d50 | > = 50% | |||
| CRI (Ra) | > = 95 | |||
| Shadow dilution with tube | 0.95 | |||
| Shadow dilution with 1 mask | 0.73 | |||
| Shadow dilution with 2 masks | 0.6 | |||
| Shadow dilution with tube and 1 mask | 0.68 | |||
| Shadow dilution with tube and 2 masks | 0.55 | |||
| Illumination depth (L1 + L2) (mm) | 1000 | |||
| Ee | 500W / M ’ | |||
| Radiant energy (W / m2 x Lux) | 4 | |||
| Bulb Life (hours) | fifty | |||
| Additional characteristics | LED, ceiling mount, Φ60cm and Φ60cm | LED, ceiling mount, Φ60cm | LED, mobile, Φ60cm, without battery | LED, mobile, Φ60cm, without battery |
Additional Information
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Model | YR02106, YR02108, YR02110, YR02112 |
| Variación | LED, ceiling-mount , Φ60cm, LED, ceiling-mount , Φ60cm&Φ60cm, LED, mobile , Φ60cm, with battery, LED, mobile , Φ60cm, without battery |
